德國TEM 飛秒激光重頻鎖定-光學鎖相環BOMPD

品牌：德國TEM
型號： BOMPD
產地：歐洲德國
供應商報價：面議

上海昊量光電設備有限公司更新時間：2025-04-22 10:04:54

銷售范圍售全國

入駐年限第10年

營業執照已審核

同類產品光學頻率梳(11件)

立即掃碼咨詢

聯系方式：400-855-8699轉8191

聯系我們時請說明在儀器網（www.ghhbs.com.cn）上看到的!

掃碼分享

為您推薦

詳細介紹

飛秒激光重頻鎖定器-光鎖相環可以高精度地檢測光脈沖序列與微波信號零交叉之間的時間延遲。它生成一個基帶信號，該信號與兩個輸入之間的時間誤差成正比，從而可以在鎖相環配置中用于將激光與微波源緊密同步，反之亦然。由于其采用平衡光學探測的檢測方案，使得飛秒脈沖重頻鎖定器對光源和微波源的幅值波動都具有免疫能力，大大zyi制了光檢測過程中的AM-PM轉換噪聲。

應用

超快激光重頻與微波信號的同步鎖定
微波信號與超快激光重頻之間的同步鎖定
微波源與穩定光纖鏈路輸出的同步
由超快光學振蕩器產生超低噪聲微波信號
與束到達監測器(BAM)一起使用時，超快激光與加速器中電子束的同步

規格

Parameter	Value	Unit	Comment
Detector sensitivity	> 0.05	mV / fs	At the detector output (not amplified)
Detector resolution	< 0.5	fs	Integrated detector noise floor within 10 kHz bandwidth
Control system	included		Available in Epics, Tango…
Auto lock	included
Dimensions			Rack mountable, 19 inch width, 5HU
Weight	10-20	kg	Depending on options

RF input power	>15	dBm	Up to 10 GHz. BOMPD tailored to frequency of interest
Optical input wavelength	800 ± 30 1550 ± 40	nm	Operating at pulsed mode
Optical input power	> 50* > 20**	mW	* Required average power for 800nm version ** Required average power for 1550nm version
Optical input type	PM Fiber		FC or SC connector
Pulse repetition rate	< 10	GHz	BOMPD is tailored for the repetition rate of interest
RF Generation Option for BOMPD
VCO	Included		Customizable upon request
Integrated feedback	Included		Optimized PID parameters
Timing Jitter	< 30	fs RMS	Within 35 μHz - 1 MHz bandwidth; relative to the master oscillator
RF output frequency	< 10	GHz	Can be tailored for the frequency of interest
Locking bandwidth	> 10	kHz	Between the optical master and RF slave oscillator
RF output power	> 10	dBm	50 Ω impedance
RF power stability	< 0.1	%
Low Noise Option for BOMPD
VCO	Included
Timing Jitter	< 5	fs RMS	Within 35 μHz - 1 MHz bandwidth; relative to the master oscillator
